Artec – SR20 Cast Top Mount V-Band manifold

Original price was: AUD $1,395.00.Current price is: AUD $1,365.00.

SKU: ART-SR-VB Categories: , ,

The Artec Cast SR20 manifold has been designed to accept a wide variety of turbos that use a 50 to 55mm ID on the inlet flange, These include Precision , Tial, and Garrett. The wastegate has been positioned to allow for easy routing for a plumb back or vent to air layout. The wastegate comes fully machined to accept most 44/45/46mm wastegates. The wastegate pipe is also designed to flow up to a 50mm wastegate unit, so you would simply cut our flange off and weld the bigger unit on , if required.

We use 34mm ID runner (others normally use a 36/39/42) to help keep throttle response up, as well as transitioning from the SR20 exhaust port shape to our runner over a length of 45mm to aid in flow.

The design allows for very easy oil and water line routing.

The V-band also allows you to run a straight forward facing turbo layout our pointed out to the side depending on the owners taste and turbo selection.

  • Cast Stainless Construction
  • New design
  • 347 Stainless
  • Lifetime warranty (to original purchaser)

Additional information

Weight 6.5 kg
Dimensions 60 × 25 × 20 cm
