Elite Race Expansion Module (REM) + 16 Injector Upgrade Universal Wire-in Harness Kit

LENGTH: 2.5m (8')

OUTPUTS: Up to 8 injectors and auxillary I/O.

SUITS: Universal 1 - 12 cylinder or 2-4 rotor applications. Up to 16 sequential injector upgrade.

INCLUDES: Elite REM with Advanced Torque Management and Race Functions. Universal upgrade Wire-in Harness with 75A SSR, USB programming cable and USB Software Key.

NOTES: Used to add an Elite REM to an exisiting Elite 2500 installation. DBW function not available when used in combination with a REM. 8 individual ignition coil ready when used with optional HT-130306, HT-130311, HT-130312 or HT-130313.
The fastest and most cost effective start to building your custom your race car or engine conversion harness.

• coded and labelled wires that match the detailed wiring diagram for a confusion free construction process.

• wiring diagram is accompanied by the full ECU manual and Software located on the CD or USB key provided with the ECU to refer to while completing your installation and configuration.

The Race Expansion Module (REM) is used in conjunction with the Haltech Elite 2500 ECU to offer extra Input and Output functionally as well as Advanced Torque Management. Using the REM with the Elite 2500 allows sequential staged injection of up to 16 injectors, and will drive up to 32 injectors. The REM also has additional Analogue and Digital inputs which can be used for data acquisition as well as additional Digital outputs.

• 8 x Fuel Injection Outputs
• 4 x Digital Pulsed Outputs
• 4 x Digital Pulsed Outputs
• 4 x Digital Pulsed Inputs
• 8 x Analogue Voltage Inputs (with selectable Pull up)
• 2 x Buffered Analogue Voltage Inputs suitable for O2 Sensors

• 1 x Haltech CAN Connection
• 2 x System Synchronisation Pulsed Inputs
• 1 x System Synchronisation Watchdog Output
• 1 x Injection Relay Control Output
• 1 x 8VDC Injection Relay Conditioning Circuit Supply
