Garrett G25-660 Turbo

Sold Out

AUD $3,195.00

Custom Product - COVID-19 circumstances and huge demand has caused us longer than expected delays. Please allow 5-7 weeks to manufacture this product.

SKU: G25-660 Category:

Introducing performance out of a package you never thought possible. This clean sheet product is tailored to meet the demands of hard core racing enthusiasts while providing industry leading power capability in a small package.

  • Garret G series compressor aerodynamics for maximum HP
  • New turbine wheel aerodynamics improved flow and boost response;
  • Turbine wheel flows 15-20% more than GTX peak efficiency of 74%
  • Turbine wheel constructed of Mar-m Alloy rated for 1055deg C
  • Stainless Steel turbine housings T25 & V-band options, intergrated wastegates and non-wastegated versions
  • OIl restrictor & water fittings included
  • New twin piston ring oil seals on bearing cartridge
  • New centre housing v-band to turbine housing clamping
  • Multiple large water jacket port connection points
  • Fully machined speed senor & pressure ports



Compressor Inducer: 54mm
Compressor Exducer: 67mm
Compressor Trim: 65
Compressor A/R: 0.7
Turbine Inducer: 54mm
Turbine Exducer: 49mm
Turbine Trim: 84



Additional information

Weight 9 kg
Dimensions 32 × 32 × 32 cm
